Magicycle Deer Step-over E-Bike With An Extra 20Ah Battery
Original price was: $3,148.00.$2,149.00Current price is: $2,149.00.
-
A full-suspension fat-tire e-bike bundle with dual 20 Ah batteries, 750 W motor, and rugged off-road capability—perfect for epic long-range adventures.
Out of stock
The Magicycle Touring E‑Bike Bundle includes a full-suspension fat-tire e-bike and an additional 52V 20Ah battery, ideal for long-distance Touring adventures. With a powerful 750 W motor (1,500 W peak), full hydraulic suspension, and rugged design, this setup delivers up to 100 miles per charge and supports a 450 lb payload.
Key Features
-
750 W Hub Motor (1,500 W Peak): Delivers strong acceleration and torque for trail riding.
-
Dual 52 V 20 Ah Batteries: Doubles range—up to an estimated 200 miles in total.
-
Full Hydraulic Suspension: Front and rear shocks ensure a smooth, controlled ride across rough terrain.
-
26″×4″ Fat Tires: Provide stability, traction, and comfort on sand, snow, and dirt roads.
-
Hydraulic Disc Brakes: Dual 180 mm brakes offer safe and responsive stopping.
-
450 lb Payload Capacity: 6061 aluminum frame accommodates riders and cargo.
Technical Specifications
| Specification | Details |
|---|---|
| Motor | 750 W (1,500 W peak), ~100 Nm torque hub |
| Battery | Dual 52 V 20 Ah lithium packs (total 2,080 Wh) |
| Range | Approx. 100 miles per battery (≈200 miles total) |
| Top Speed | Up to 28 MPH (Class 3 pedal assist) |
| Suspension | Hydraulic fork + rear shock |
| Tires | 26″×4″ fat tires |
| Brakes | Dual 180 mm hydraulic discs |
| Frame | 6061 alloy supports a 450 lb payload |
| Weight | Approx. 92 lb (41.9 kg) |
| Brand | |
|---|---|
| Motor | 750W |
| Range | |
| Top Speed | 28 MPH (Class 3) |
| Suspension | Front hydraulic fork + rear shock |
| Tire Type | Fat Tires |
| Frame | 6061 Alloy Supports a 450 lb Payload |
| Full Suspension | Front & Rear Shock |
| High-Power Motor | 750W/1500W peak |
| Payload Capacity | Max 450 lbs |
| Charging Time | 4 – 7Hours |
| Weight | Deer 26″: 92.3lbs(41.9kg) / 20″: 83lbs(37.6kg) |
| Package Dimension | Deer 26″: 166CM x 33CM x 88.5CM /20″: 154CM x 32CM x 77.5CM; |
| Charger | Short-circuit proof 3.0A fast smart charger |
| Recommended Rider Heights | Deer 26″: 5’5″ – 6’8″ / 20″: 4’10” – 6’2″ |
| Hub Motor | 750W/1500W(peak) 100Nm brushless gear motor(IP55) |
| Controller | 52V 750W FOC smart controller, Current Range 20~25 Amps (IPX8) |
| Frame size | 18″ |
| Display | Color LCD Display with USB Charging |
| Pedal Assist | 7-level Intelligent pedal assist with 12-magnet cadence sensor |
| Brake Lever | Aluminum alloy comfort grip levers with motor cutoff switch |
| Lights | Integrated front and brake lights |
| Freewheel | Shimano-14-28T BROWN/BK |
| Spokes | 13 Gauge on the front / 12 Gauge on the back |
| Front Light | 6V LED light |
| Saddle | Super Soft Cushion |
| Seat Post | Diameter 33.9mm length 250mm |
| Kickstand | Heavy duty aluminum |
| Bike Frame | 18″ 6061 Aluminum Frame |
| Front Fork | Alloy Hydraulic lockout suspension fork |
| Throttle | Half twist throttle |
| Pedal | Wellgo alloy pedal with reflectors |
| Gearing | Shimano 7 speed gear shift system |
| Chain | KMC chain |
| Stem | MA-400 SSABK |
| Crank | 53T, 170mm forged alloy, dual-sided bashguard |
